API documentation is crucial for any modern web application. In this guide, I'll walk you through implementing Scalar API documentation with multi-version support in .NET 10. Scalar provides a beautiful, interactive documentation UI that's more modern and user-friendly than traditional Swagger.

What We'll Build

Prerequisites

Install the Scalar package:

<PackageReference Include="Scalar.AspNetCore" Version="1.2.65" />

That's it! No API versioning packages needed.

Step 1: Create Version-Specific Controllers

The key is using [ApiExplorerSettings(GroupName = "vX")] on your controllers.

V1 Controller

[Route("api/v1/villa")]
[ApiExplorerSettings(GroupName = "v1")]
[ApiController]
public class VillaController : ControllerBase
{
    [HttpGet]
    public async Task<IActionResult> GetVillas()
    {
        var villas = await _db.Villa.ToListAsync();
        return Ok(villas);
    }
}

V2 Controller (with Pagination)

[Route("api/v2/villa")]
[ApiExplorerSettings(GroupName = "v2")]
[ApiController]
public class VillaController : ControllerBase
{
    [HttpGet]
    [Authorize]
    public async Task<IActionResult> GetVillas(
        [FromQuery] int page = 1,
        [FromQuery] int pageSize = 10)
    {
        var skip = (page - 1) * pageSize;
        var villas = await _db.Villa.Skip(skip).Take(pageSize).ToListAsync();
        return Ok(villas);
    }
}

Step 2: Register OpenAPI Documents

Simple - just one line per version!

builder.Services.AddOpenApi("v1");
builder.Services.AddOpenApi("v2");

Step 3: Configure Scalar UI

var app = builder.Build();

app.MapOpenApi();

app.MapScalarApiReference(option =>
{
    option.Title = "Royal Villa API";

    option
        .AddDocument("v1", "API Version 1.0", "/openapi/v1.json", isDefault: true)
        .AddDocument("v2", "API Version 2.0", "/openapi/v2.json");
});

Step 4: Controller Attributes Explained

The Magic: ApiExplorerSettings

[ApiExplorerSettings(GroupName = "v1")]

This is the most important attribute for Scalar's multi-document feature! It tells the OpenAPI generator:

Example:

// V1 Controller - appears ONLY in v1 document
namespace RoyalVilla_API.Controllers.v1
{
    [Route("api/v1/villa")]
    [ApiExplorerSettings(GroupName = "v1")]  // ?? Key attribute!
    [ApiController]
    public class VillaController : ControllerBase
    {
        [HttpGet]
        public async Task<IActionResult> GetVillas()
        {
            var villas = await _db.Villa.ToListAsync();
            return Ok(villas);
        }
    }
}

// V2 Controller - appears ONLY in v2 document
namespace RoyalVilla_API.Controllers.v2
{
    [Route("api/v2/villa")]
    [ApiExplorerSettings(GroupName = "v2")]  // ?? Different group!
    [ApiController]
    public class VillaController : ControllerBase
    {
        [HttpGet]
        [Authorize]
        public async Task<IActionResult> GetVillas(
            [FromQuery] int page = 1,
            [FromQuery] int pageSize = 10)
        {
            // Pagination logic
            return Ok(villas);
        }
    }
}

Route Templates

// V1 - Explicit version in route
[Route("api/v1/villa")]

// V2 - Also explicit (we keep it simple!)
[Route("api/v2/villa")]

Both use explicit versioning in the route. This is the simplest and most readable approach.

Step 5: Testing the API Documentation

Access Your Documentation

Version Switching

Click the version dropdown in the top-right to switch between:

• • API Version 1.0 - Simple CRUD operations
• • API Version 2.0 - Paginated results with authentication

💡 Production Considerations

While our tutorial focuses on simplicity to teach the core concepts, here are some professional improvements you might consider for production:

1. Generic Response Model

Our examples use simple IActionResult with direct returns:

[HttpGet]
public async Task<IActionResult> GetVillas()
{
    var villas = await _db.Villa.ToListAsync();
    return Ok(villas);  // ✅ Simple, but no standardization
}

For production, consider a generic response wrapper for consistency:

public class ApiResponse<T>
{
    public bool Success { get; set; }
    public int StatusCode { get; set; }
    public string Message { get; set; }
    public T? Data { get; set; }
    public string? Errors { get; set; }
}

[HttpGet]
public async Task<ActionResult<ApiResponse<IEnumerable<VillaDTO>>>> GetVillas()
{
    var villas = await _db.Villa.ToListAsync();
    var response = ApiResponse<IEnumerable<VillaDTO>>.Ok(villas, "Villas retrieved successfully");
    return Ok(response);  // ✅ Standardized response format
}

🚀 Best Practices

1. Versioning Strategy

For Scalar multi-document, we use:

URL Versioning with GroupName: /api/v1/villa + [ApiExplorerSettings(GroupName = "v1")] ✅

Simple, explicit, and works perfectly with Scalar.

Alternative approaches (if you need full API versioning middleware):

• • Dynamic Route with ApiVersion: [Route("api/v{version:apiVersion}/villa")] + [ApiVersion("1.0")]
• • Header Versioning: api-version: 1.0 header
• • Query String: /api/villa?version=1.0

All of these require API versioning middleware, which we've intentionally avoided for simplicity!

2. Controller Organization

Keep versions in separate namespaces:

Controllers/
+-- v1/
¦   +-- VillaController.cs
¦   +-- VillaAmenitiesController.cs
+-- v2/
¦   +-- VillaController.cs
¦   +-- VillaAmenitiesController.cs

Each controller has [ApiExplorerSettings(GroupName = "vX")] - that's the key!

3. Backward Compatibility

• • Never break v1 - Keep it stable
• • Add features in v2 - Don't remove v1 functionality
• • Deprecate gracefully - Give users time to migrate

🎬 Conclusion

We've successfully implemented a professional-grade API documentation system using Scalar with multi-version support. The best part? It's incredibly simple!

Now go build some amazing APIs with beautiful documentation!
